Ideal for Petroleum, chemical industry, coal mine, mining industry, shipbuilding, port industry, petrochemical, metallurgical industry
Offered in 50W-120W
Light efficiency up to 140lm/W
Lumileds chips, High brightness, Low light decay & long lifetime
International driver brand, overheat protection, high convert efficiency, high PF & surge protection, (1-10V,DALI2.0)
Die-casting technology with ADC12, excellent thermal management
Optical UV resistant PC lens with 94% light transmitiance, IK08.
CODING: Ex db lIC T6 Gb; Ex tb lIC T80C Db
Working Temperature: -35℃ to +50℃
Storage Temperature: -35℃ to +50℃
Working Humidity: 0%~85%
Storage Humidity: 0%~90%
Warning
1. Please install the lamp according to the installation to avoid dropping and electric shock.
2. Don't exchange the lamp as will to avoid dropping ,electric shock and damage of the lamp.
3. Working voltage is not to be exceeded AC100-277V 50/60Hz.
Attention
1. Don't install the lamp to non-stable place.
2. Installed by qualified electrician.
3. Switch off the switch box and contact certified electrician if the lamp works abnormally.
| Model No. | ISL-EX01-C-50W | ISL-EX01-C-70W | ISL-EX01-C-100W | ISL-EX01-C-120W |
| Rated Power | 50W | 70W | 100W | 120W |
| Light Efficiency | 140lm/W | |||
| Input Voltage | AC100-277V, 50/60Hz | |||
| LED Chip | Lumileds | |||
| Beam Angle | 120° | |||
| CCT | 3000K/ 4000K/ 5000K/ 5700K/ 6500K | |||
| CRI | 80Ra | |||
| IP Rating | IP65 | |||
| IK Rating | IK08 | |||
| Warranty | 3Years/ 5Years | |||
| Lifespan | 50,000Hrs | |||
| Dimension | 222*189mm | 222*189mm | 262*212mm | 262*212mm |
| Certificate | Ex db IIC T6 Gb/Ex tb IIIC T80℃ Db | |||
