Roads, highways, viaducts, city streets, overpasses, sidewalks, and outdoor lighting places such as squares, schools, residential areas and parks.>
Offered in 50W-300W
Light efficacy up to 150lm/W
Die-casting technology with ADC12, excellent thermal management
Optical UV resistant PC lens with 94% light transmittance, IK08.
Light Distribution: T2-M, T3-M
Top brand LED chip and driver, ensure the product quality and lifetime
Ingress protection: IP66 waterproof
Double surge protection: Driver & extra 10KV SPD
Working Temperature：-35~+50℃
Storage Temperature：-35~+50℃
Working Humidity：0%~85%
Storage Humidity：0%~90%
| Model No. | ISL-LD-C50W | ISL-LD-C100W | ISL-LD-C150W | ISL-LD-C200W | ISL-LD-C250W | ISL-LD-C300W |
| Rated Power | 50W | 100W | 150W | 200W | 250W | 300W |
| Light Efficiency | 150lm/W | |||||
| Model No. | ISL-LD-C60W | ISL-LD-C120W | ISL-LD-C180W | ISL-LD-C240W | ISL-LD-C300W | ISL-LD-C360W |
| Rated Power | 60W | 120W | 180W | 240W | 300W | 360W |
| Light Efficiency | 140lm/W | |||||
| Input Voltage | AC100-277V, 50/60Hz | |||||
| LED Chip | Lumileds | |||||
| Driver | Sosen/ Meanwell | |||||
| Beam Angle | T2-M/ T3-M | |||||
| CCT | 3000K/ 4000K/ 5000K/ 5700K/ 6500K | |||||
| CRI | 80Ra | |||||
| IP Rating | IP66 | |||||
| IK Rating | IK08 | |||||
| Warranty | 5Years | |||||
| Lifespan | 50,000Hrs | |||||
| Dimension | 483*313*93mm | 558*313*93mm | 634*313*93mm | 709*313*93mm | 785*313*93mm | 860*313*93mm |
| Certificate | CQC/TUV/CB/CE/SAA/FCC/RoHS | |||||
Warning
1. Please install the lamp according to the installation to avoid dropping and electric shock.
2. Don't exchange the lamp as will to avoid dropping ,electric shock and damage of the lamp.
3. Working voltage is not to be exceeded AC100-277V 50/60Hz.
Attention
1. Don't install the lamp to non-stable place.
2. Installed by qualified electrician.
3. Switch off the switch box and contact certified electrician if the lamp works abnormally.
