It can be widely used in Workshops, Warehouse, Exhibition halls, Supermarkets, Gyms, Indoor stadiums, Gas stations, Logistics centers, Underground parking lots, etc
Offered in 150W, 200W, 300W-800W
Lumileds chips, high brightness, low light decay & long lifetime
International driver brand, overheat protection, high convert efficiency, high pf & surge protection, (1-10V,DALI2.0)
Die-casting technology with ADC12, excellent thermal management
4mm high strength tempered glass, further reduces the UV and anti-rust, typically designed for coastal areas
Bracket installation, operation temperature: -35℃- +65℃
Working Temperature: -35℃ to +65℃
Storage Temperature: -35℃ to +65℃
Working Humidity: 0%~85%
Storage Humidity: 0%~90%
Warning
1. Please install the lamp according to the installation to avoid dropping and electric shock.
2. Don't exchange the lamp as will to avoid dropping ,electric shock and damage of the lamp.
3. Working voltage is not to be exceeded AC100-277V 50/60Hz.
Attention
1. Don't install the lamp to non-stable place.
2. Installed by qualified electrician.
3. Switch off the switch box and contact certified electrician if the lamp works abnormally.
| Model No. | ISL-HT-A150W | ISL-HT-A200W | ISL-HT-A300W | ISL-HT-A400W | ISL-HT-A500W | ISL-HT-A600W | ISL-HT-A800W |
| Rated Power | 150W | 200W | 300W | 400W | 500W | 600W | 800W |
| Light Efficiency | 150lm/W | ||||||
| Input Voltage | AC100-277V, 50/60Hz | ||||||
| LED Chip | Lumileds | ||||||
| LED Driver | Sosen | ||||||
| Beam Angle | 120° | 30°/ 60°/ 90° | |||||
| CCT | 3000K/ 4000K/ 5000K/ 5700K/ 6500K | ||||||
| CRI | 80Ra | ||||||
| IP Rating | IP65 | ||||||
| IK Rating | IK08 | ||||||
| Operation Temperature | -35℃- +65℃ | ||||||
| Warranty | 5Years | ||||||
| Lifespan | 50,000Hrs | ||||||
| Dimension | ø280*400mm | ø320*400mm | ø448*485mm | ø448*485mm | ø448*485mm | ø598*507mm | ø598*507mm |
| Certificate | CB/CE/ENEC/SAA/FCC/RoHS | ||||||
